| Specifications |
Effective |
Effective |
Web |
Theoretical |
Standard |
| Breath |
Height |
Thickness |
Weight |
| (mm) |
(mm) |
(t) mm |
(kgs/m) |
| U400*100 |
400 |
100 |
10.5 |
48 |
GB/T20933-2014 JIS A5528 |
| U400*125 |
400 |
125 |
13 |
60 |
| U400*150 |
400 |
150 |
13.1 |
58.4 |
| U400*170 |
400 |
170 |
15.5 |
76.1 |
| U500*210 |
500 |
210 |
11.5 |
77.5 |
| 500 |
210 |
15.6 |
87.5 |
| 500 |
210 |
20 |
103 |
| U500*200 |
500 |
200 |
24.3 |
105 |
| U500*225 |
500 |
225 |
27.6 |
120.1 |
| U600*130 |
600 |
130 |
10.3 |
61.8 |
| U600*180 |
600 |
180 |
13.4 |
81.6 |
| U600*210 |
600 |
210 |
18 |
106.2 |
| U750*205 |
750 |
204 |
10 |
77.9 |
| 750 |
205.5 |
11.5 |
86.3 |
| 750 |
206 |
12 |
89 |
| U750*220 |
750 |
220.5 |
10.5 |
88.5 |
| 750 |
222 |
12 |
96.9 |
| 750 |
222.5 |
12.5 |
99.7 |
| U750*225 |
750 |
223.5 |
13 |
102.1 |
| 750 |
235 |
14.5 |
110.4 |
| 750 |
225.5 |
15 |
113.2 |
| Steel Grade |
Chemical Composition % Max |
CEV |
Mechanical Property |
| C |
Si |
Mn |
P |
S |
V |
Nb |
Ti |
Max |
Yield Strength N/mm2 max |
Tensile Strength N/mm2 max |
Elongation A % Max |
| Q295P |
0.16 |
0.5 |
1.5 |
0.035 |
0.035 |
0.15 |
0.06 |
0.2 |
0.4 |
295 |
390~570 |
23 |
| Q345P |
0.2 |
0.5 |
1.7 |
0.035 |
0.035 |
0.15 |
0.06 |
0.2 |
0.42 |
345 |
480~630 |
22 |
| Q390P |
0.2 |
0.5 |
1.7 |
0.035 |
0.035 |
0.2 |
0.06 |
0.2 |
0.44 |
390 |
490~650 |
20 |
| Q420P |
0.2 |
0.5 |
1.7 |
0.035 |
0.035 |
0.2 |
0.06 |
0.2 |
0.46 |
420 |
520~680 |
19 |
| Q460P |
0.2 |
0.6 |
1.8 |
0.03 |
0.03 |
0.2 |
0.11 |
0.2 |
0.46 |
460 |
550~720 |
17 |
